Zetalase™ XL Laser Marking System

Zetalase™ XL is a full-size, floor-standing laser marking system with a variety of laser options and accessories.

Request Information

Product Details

Zetalase™ XL offers an expansive work area and is highly configurable for a variety of applications and is ideal for the processing of large components or trays of parts. Standard programmable focal height is controlled via software for automatic focus adjustment between part types. A front vertical pneumatic door with a patented safety system, recessed front operator footrest, and machine auto mode maximize ergonomics for high-volume processing. Have large or long parts to process? Class 4 capability for open door marking is possible with our service override key, removable side panels, safety warning lights, and optional laser safety glasses. Available options include a gantry Y-axis for increased marking field size and rotary devices for marking around the diameter of components.

Zetalase XL Angle View Door Closed No BG

Laser Marking System Features

  • Class 1 Safe Floor Standing Full-Size Laser Enclosure
  • Front Operator Membrane Control Panel
  • Vertical Pneumatic Door with Patented Safety System and Auto Start Mode
  • Laser Options Include a 20W to 100W MOPA Fiber Laser
  • Programmable Focal Height Adjustment
  • Integrated Windows 10 Pro PC with Monitor, Keyboard, and Mouse on a Gas Assisted Adjustable Swing Arm
  • Optional Gantry Linear Y-Axis, Rotary Devices, Pull-out Part Loading Shelf, and More
  • Class 4 Mode with Interlock Override Key, Removable Side Panels, Warning Lights, and Laser Safety Glasses

Major Features

Full-Size Floor-Standing Enclosure

Our Zetalase XL’s full-size Class 1 laser enclosure provides safe operator use without the need for protective eyewear.

laser engraving machine
laser engraving machine

A Variety of Options

Our unit is highly configurable, with options such as a gantry Y-axis for increased marking field size, rotary devices, and more.

Ergonomic, High-Volume Design

This system is ideal for high-volume applications. The vertical pneumatic door opens and closes automatically with each marking cycle. In addition, the system can be put into Class 4 mode to mark larger parts with the door open.

laser engraving machine
